Please note: This brake can only be installed on the models with the brake disc on the left side, excluding the models installed on the upper left side. If you do not understand, please contact us and we will give you an accurate recommendation!

The above picture is the relevant dimensions of the brake handle. If you still have any unfamiliar dimensions, please contact customer service and we will measure the relevant dimensions for you!

The length of the power-off wire is about 200mm, waterproof 2-pin connector, we also have 3-pin and 1.5-meter extension connector, if you need, please contact customer service!

The power-off function of the power-off wire has been debugged before leaving the factory. Please do not adjust it if it is not necessary!

We have filled the brake levers and calipers with mineral oil before leaving the factory, and you can use them directly after you receive the products!

Our brakes are made of aluminum alloy forged and then CNC machined, with good strength, high hardness and durability!

The appearance is anodized after fine grinding and will never fade!

The hydraulic brake lever is an integrated oil cylinder structure, which is durable and does not leak oil!

The structure of the brake handle is shown. The power-off principle of the brake handle is magnetic induction, which is very sensitive. The distance has been adjusted at the factory. Non-professionals, please do not adjust it at will!

The above picture is an all-round picture of the clamp. The four directions allow you to see clearly and the quality is close at hand. There are pictures and truths in the actual shooting!

The overall size of the clamp is about 90x35x39mm, the length of the tubing is 2300mm, and the length of the 30mm film is the same as the size of M355/M395, so it can be used universally!

The brake caliper is a double-cylinder double-acting structure, the brake is sensitive, the hand feels light, and it is strong and durable!

The picture above shows the black caliper, which is suitable for the left brake disc (the model with the disc on the right cannot be used), the length of the oil pipe is 2300mm, you can cut it according to your own needs, and the caliper has been filled with mineral oil!

Warning: Before installing the brake disc, please do not remove the red blocking plate to empty the brake lever, otherwise it will cause oil leakage or damage to the oil disc!

①Measure the length of the tubing and cut it
②Press the oil needle with a tool
③ Unscrew the plug screw on the brake lever (discarded)
④Insert the oil pipe into the brake lever and press the copper sleeve with the pressing screw to complete the installation

! ! ! PLEASE NOTE: Your brake purchase does not include tools! If you need, please contact customer service to buy Or buy in-store This shop has sales!

If the brake caliper in the picture ① position interferes with the tire or the hub motor, you can install the shop shown in picture ③ between the brake disc and the wheel hub in picture ② to solve the interference problem!

Individual scooters may interfere with tires or motors. We provide you with a set containing gaskets, please pay attention to selection!

The picture above is a black set including 1 left and right brake levers, 2 calipers, the base and accessories as shown in the picture, suitable for bicycle shops or maintenance personnel with tools and technical skills to buy

The picture above shows a black set of additional oil pipe tools, oil needle pressing tools, mineral oil and oil change and exhaust tools, suitable for personal purchase!

The picture above is a set of black additional oil pipe tool, oil needle pressing tool, mineral oil and oil change and exhaust tool, and additional brake disc 160mm disc screw 12pcs

The picture above is a black set, plus 2 brake discs 160mm, brake disc screws 12pcs

The picture above is a Red set including 1 left and right brake levers, 2 calipers, the base and accessories as shown in the picture, suitable for bicycle shops or maintenance personnel with tools and technical skills to buy

The picture above shows a red set of additional oil pipe tools, oil needle pressing tools, mineral oil and oil change and exhaust tools, suitable for personal purchase!

The picture above is a set of Red additional oil pipe tool, oil needle pressing tool, mineral oil and oil change and exhaust tool, and additional brake disc 160mm disc screw 12pcs

The picture above is a black set, plus 2 brake discs 160mm, brake disc screws 12pcs

Factory photo:
